Description:
It adopts a high-intensity tooth holding row and all-around registering system for working accurately.
There is highly precise intermittent equipment, pneumatic clutchand Pneumatic plate lock equipment programmed controllerHuman machine interface shows workload speed and running time error detector show makes troubleshooting easy.
The main motor is controlled by the inverter to continuously variable transmission for stable working sensors and a safe system guarantees working and workers.
Die cutting pressure can be changed. Hand cracking is easy to access.
Technical Parameter
| Max sheet size | 1060mm x 760mm |
| Min sheet size | 420mm x 350mm (standard)II 420mmx270mm (pattern optional) |
| Max die cutting size | 1050mm x 750mm |
| Gripper margin | ≥6mm |
| Inner chase size | 1120mm x 786mm |
| Paperboard range | 80-2000G/m2 paper, paperboard, solid board, corruated board ≤4mm |
| Die cutting accuracy | ≤ ± 0.075mm |
| Max die cutting force | 300tons |
| Max die-cutting speed | 7500s/h |
| Max feeder | 1600mm(wooden pallet included) |
| Max delivery pile height | 1500mm(wooden pallet included) |
| Air requirement | 0.6~0.7Mpa > 0.6m3/min |
| Net weight approx | About 16 tons |
| Main motor wattage | 11KW |
| Full load wattage | 17KW |
| Overall dimension | 6500mm(L:Pre-load paper device included)x4000mm(W:Platform included)x2300mm(H) |
