Description
- Paper feeder adopts no shaft-free servo drive with non-stop device
- Electric heating powder removal system
- Using double servo system to control the paper overlap to match sure the precise of the paper overlap.
- Adopt German electromagnetic induction heating energy saving system will be used for upper and lower steel roller heating.
- Glue on smooth ceramic roller, so that the glue is evenly coated and save glue, ceramic roller can also do colored glue coating, spot color coating does not need to go to the printing press.
- Control board is using wall - mounted computer screen intelligent operation.
- Adopts the automatic constant temperature power governor. Machine can adjust the temperature up and down according to the speed of production speed to saving more energy intelligent.
- Cooling device after laminating.
- Automatic cutter is advance and retreat intelligent.
- The wall of the whole machine is made of integral wall board and processed by large machining center machine tool, so the stability of the equipment is strengthened compared with before and others.
Specification
| Model | 1080 |
| Max. Paper Size | 1080X1050mm |
| Min. Paper Size | 350x295mm |
| Paper Thickness (G/m2) | 80-500 |
| Height of feeding pile | 1060mm |
| Paper Delivery Height | 1060mm |
| Film Thickness | 0.01-0.02mm |
| Power Required | 60kw(Actual power consumption 20-25kw/ hour |
| Laminating Speed | 50-70m/min |
| Dimension{LxWxH) | 11000x2100x2650mm |
| Machine Weight | 7200kg |
